The Magento 2 Checkout Shipping Address Form is an essential part of the checkout process, allowing customers to enter their shipping information. It can be customized to improve the user experience, such as by moving the billing address below the shipping address, making the checkout flow simpler and more efficient for customers. This customization enhances customer satisfaction and increases the likelihood of successful purchases.
Contents
Magento 2 Default Checkout Steps
By default, the customer must add Shipping Address information, select the Shipping Method, and then go to the second checkout step including Billing Address and Payment Method.
Shipping Address (in the first step of checkout)
Billing Address (in the second step of checkout)
Magento 2 Custom Checkout
After moving the Billing Address section to the first checkout step – under Shipping Address, the checkout flow seems to be more rational. In the second step, the buyer only needs to complete the Payment fields and review the order.
How To Move Billing Address Under Shipping Address In Magento Checkout
In order to increase customer experience in Magento 2 websites, many store owners want to change the order of the billing address in the checkout page. To be more specific, they want to move/ place the billing address right under the shipping address in the first step of checkout. As a result, the buyer can easily complete the address fields and move to the next step.
Step 1: Create the file app\code\Tigren\AdvancedCheckout\etc\module.xml
<?xml version="1.0"?> <config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:Module/etc/module.xsd"> <module name="Tigren_AdvancedCheckout" setup_version="1.0.0"> <sequence> <module name="Magento_Checkout"/> </sequence> </module> </config>
Step 2: Create the file app\code\Tigren\AdvancedCheckout\registration.php
<?php /** * @author Tigren Team * @copyright Copyright (c) 2015 Tigren (https://www.tigren.com) * @package Tigren_AdvancedCheckout */ \Magento\Framework\Component\ComponentRegistrar::register( \Magento\Framework\Component\ComponentRegistrar::MODULE, 'Tigren_AdvancedCheckout', __DIR__ );
Step 3: Create the file app\code\Tigren\AdvancedCheckout\etc\di.xml to declare the plugin
<?xml version="1.0"?> <config xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" xsi:noNamespaceSchemaLocation="urn:magento:framework:ObjectManager/etc/config.xsd"> <type name="Magento\Checkout\Block\Checkout\LayoutProcessor"> <plugin name="tigren_modified_checkout_layout_processor" type="Tigren\AdvancedCheckout\Plugin\Block\LayoutProcessor" sortOrder="1"/> </type> </config>
Step 4: Create the file app\code\Tigren\AdvancedCheckout\Plugin\Block\LayoutProcessor.php to insert Billing Address form
<?php namespace Tigren\AdvancedCheckout\Plugin\Block; use Magento\Customer\Model\AttributeMetadataDataProvider; use Magento\Ui\Component\Form\AttributeMapper; use Magento\Checkout\Block\Checkout\AttributeMerger; use Magento\Checkout\Model\Session as CheckoutSession; class LayoutProcessor { /** * @var AttributeMetadataDataProvider */ public $attributeMetadataDataProvider; /** * @var AttributeMapper */ public $attributeMapper; /** * @var AttributeMerger */ public $merger; /** * @var CheckoutSession */ public $checkoutSession; /** * @var null */ public $quote = null; /** * LayoutProcessor constructor. * * @param AttributeMetadataDataProvider $attributeMetadataDataProvider * @param AttributeMapper $attributeMapper * @param AttributeMerger $merger * @param CheckoutSession $checkoutSession */ public function __construct( AttributeMetadataDataProvider $attributeMetadataDataProvider, AttributeMapper $attributeMapper, AttributeMerger $merger, CheckoutSession $checkoutSession ) { $this->attributeMetadataDataProvider = $attributeMetadataDataProvider; $this->attributeMapper = $attributeMapper; $this->merger = $merger; $this->checkoutSession = $checkoutSession; } /** * @param \Magento\Checkout\Block\Checkout\LayoutProcessor $subject * @param array $jsLayout * @return array */ public function aroundProcess( \Magento\Checkout\Block\Checkout\LayoutProcessor $subject, \Closure $proceed, array $jsLayout ) { $jsLayoutResult = $proceed($jsLayout); if ($this->getQuote()->isVirtual()) { return $jsLayoutResult; } if (isset($jsLayoutResult['components']['checkout']['children']['steps']['children']['shipping-step']['children'] ['shippingAddress']['children']['shipping-address-fieldset'])) { $jsLayoutResult['components']['checkout']['children']['steps']['children']['shipping-step'] ['children']['shippingAddress']['children']['shipping-address-fieldset']['children']['street']['children'][0]['placeholder'] = __('Street Address'); $jsLayoutResult['components']['checkout']['children']['steps']['children']['shipping-step'] ['children']['shippingAddress']['children']['shipping-address-fieldset']['children']['street']['children'][1]['placeholder'] = __('Street line 2'); $jsLayoutResult['components']['checkout']['children']['steps']['children']['shipping-step'] ['children']['shippingAddress']['children']['billing-address']['children']['form-fields']['children']['street']['children'][0]['placeholder'] = __('Street Address'); $jsLayoutResult['components']['checkout']['children']['steps']['children']['shipping-step'] ['children']['shippingAddress']['children']['billing-address']['children']['form-fields']['children']['street']['children'][1]['placeholder'] = __('Street line 2'); } $elements = $this->getAddressAttributes(); $jsLayoutResult['components']['checkout']['children']['steps']['children']['shipping-step'] ['children']['shippingAddress']['children']['billingAddress']['children']['address-fieldset'] = $this->getCustomBillingAddressComponent($elements); if (isset($jsLayoutResult['components']['checkout']['children']['steps']['children']['billing-step']['children'] ['payment']['children']['afterMethods']['children']['billing-address-form'])) { unset($jsLayoutResult['components']['checkout']['children']['steps']['children']['billing-step']['children'] ['payment']['children']['afterMethods']['children']['billing-address-form']); }; if ($billingAddressForms = $jsLayoutResult['components']['checkout']['children']['steps']['children']['billing-step']['children'] ['payment']['children']['payments-list']['children']) { foreach ($billingAddressForms as $billingAddressFormsKey => $billingAddressForm) { if ($billingAddressFormsKey != 'before-place-order') { unset($jsLayoutResult['components']['checkout']['children']['steps']['children']['billing-step']['children'] ['payment']['children']['payments-list']['children'][$billingAddressFormsKey]); } } } return $jsLayoutResult; } /** * Get Quote * * @return \Magento\Quote\Model\Quote|null */ public function getQuote() { if (null === $this->quote) { $this->quote = $this->checkoutSession->getQuote(); } return $this->quote; } /** * Get all visible address attribute * * @return array */ private function getAddressAttributes() { /** @var \Magento\Eav\Api\Data\AttributeInterface[] $attributes */ $attributes = $this->attributeMetadataDataProvider->loadAttributesCollection( 'customer_address', 'customer_register_address' ); $elements = []; foreach ($attributes as $attribute) { $code = $attribute->getAttributeCode(); if ($attribute->getIsUserDefined()) { continue; } $elements[$code] = $this->attributeMapper->map($attribute); if (isset($elements[$code]['label'])) { $label = $elements[$code]['label']; $elements[$code]['label'] = __($label); } } return $elements; } /** * Prepare billing address field for shipping step for physical product * * @param $elements * @return array */ public function getCustomBillingAddressComponent($elements) { $providerName = 'checkoutProvider'; $components = [ 'component' => 'uiComponent', 'displayArea' => 'additional-fieldsets', 'children' => $this->merger->merge( $elements, $providerName, 'billingAddress', [ 'country_id' => [ 'sortOrder' => 115, ], 'region' => [ 'visible' => false, ], 'region_id' => [ 'component' => 'Magento_Ui/js/form/element/region', 'config' => [ 'template' => 'ui/form/field', 'elementTmpl' => 'ui/form/element/select', 'customEntry' => 'billingAddress.region', ], 'validation' => [ 'required-entry' => true, ], 'filterBy' => [ 'target' => '${ $.provider }:${ $.parentScope }.country_id', 'field' => 'country_id', ], ], 'postcode' => [ 'component' => 'Magento_Ui/js/form/element/post-code', 'validation' => [ 'required-entry' => true, ], ], 'company' => [ 'validation' => [ 'min_text_length' => 0, ], ], 'fax' => [ 'validation' => [ 'min_text_length' => 0, ], ], 'telephone' => [ 'config' => [ 'tooltip' => [ 'description' => __('For delivery questions.'), ], ], ], ] ), ]; return $components; } }
Step 5: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\layout\checkout_index_index.xml
<?xml version="1.0"?> <page xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance" layout="1column" xsi:noNamespaceSchemaLocation="urn:magento:framework:View/Layout/etc/page_configuration.xsd"> <body> <referenceBlock name="checkout.root"> <arguments> <argument name="jsLayout" xsi:type="array"> <item name="components" xsi:type="array"> <item name="checkout" xsi:type="array"> <item name="children" xsi:type="array"> <item name="steps" xsi:type="array"> <item name="children" xsi:type="array"> <item name="shipping-step" xsi:type="array"> <item name="children" xsi:type="array"> <item name="shippingAddress" xsi:type="array"> <item name="children" xsi:type="array"> <item name="billingAddress" xsi:type="array"> <item name="config" xsi:type="array"> <item name="deps" xsi:type="array"> <item name="0" xsi:type="string">checkout.steps.shipping-step.step-config</item> <item name="1" xsi:type="string">checkoutProvider</item> </item> <item name="popUpForm" xsi:type="array"> <item name="element" xsi:type="string">#opc-new-billing-address</item> <item name="options" xsi:type="array"> <item name="type" xsi:type="string">popup</item> <item name="responsive" xsi:type="boolean">true</item> <item name="innerScroll" xsi:type="boolean">true</item> <item name="title" xsi:type="string" translate="true">Billing Address</item> <item name="trigger" xsi:type="string">opc-new-billing-address</item> <item name="buttons" xsi:type="array"> <item name="save" xsi:type="array"> <item name="text" xsi:type="string" translate="true">Save Address</item> <item name="class" xsi:type="string">action primary action-save-address</item> </item> <item name="cancel" xsi:type="array"> <item name="text" xsi:type="string" translate="true">Cancel</item> <item name="class" xsi:type="string">action secondary action-hide-popup</item> </item> </item> </item> </item> </item> <item name="component" xsi:type="string">Tigren_AdvancedCheckout/js/view/billing</item> <item name="displayArea" xsi:type="string">billing-address</item> <item name="provider" xsi:type="string">checkoutProvider</item> <item name="sortOrder" xsi:type="string">1</item> <item name="children" xsi:type="array"> <item name="before-form" xsi:type="array"> <item name="component" xsi:type="string">uiComponent</item> <item name="displayArea" xsi:type="string">billing-before-form</item> <item name="children" xsi:type="array"> <!-- before form fields --> </item> </item> <item name="before-fields" xsi:type="array"> <item name="component" xsi:type="string">uiComponent</item> <item name="displayArea" xsi:type="string">billing-before-fields</item> <item name="children" xsi:type="array"> <!-- before fields --> </item> </item> <item name="address-list" xsi:type="array"> <item name="component" xsi:type="string">Tigren_AdvancedCheckout/js/view/billing-address/list</item> <item name="config" xsi:type="array"> <item name="template" xsi:type="string">Tigren_AdvancedCheckout/billing-address/custom-list</item> </item> <item name="displayArea" xsi:type="string">billing-address-list</item> </item> </item> </item> </item> </item> </item> </item> </item> </item> </item> </item> </item> </argument> </arguments> </referenceBlock> </body> </page>
Step 6: create file app\code\Tigren\AdvancedCheckout\view\frontend\web\js\action\edit-billing-address.js
define([ 'ko', 'Magento_Customer/js/model/address-list' ], function (ko, addressList) { 'use strict'; return function (address) { addressList().some(function (currentAddress, index, addresses) { if (currentAddress.getKey() === address.getKey()) { addressList.replace(currentAddress, address); } }); addressList.valueHasMutated(); return address; }; });
Step 7: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\js\model\billing-address\form-popup-state.js
define([ 'ko' ], function (ko) { 'use strict'; return { isVisible: ko.observable(false) }; });
Step 8: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\js\view\billing.js
define([ 'jquery', 'ko', 'underscore', 'matchMedia', 'mage/utils/objects', 'Magento_Ui/js/form/form', 'Magento_Customer/js/model/customer', 'Magento_Customer/js/model/customer/address', 'Magento_Customer/js/model/address-list', 'Magento_Checkout/js/model/address-converter', 'Magento_Checkout/js/model/quote', 'Tigren_AdvancedCheckout/js/model/billing-address/form-popup-state', 'Tigren_AdvancedCheckout/js/action/edit-billing-address', 'Magento_Checkout/js/action/create-billing-address', 'Magento_Checkout/js/action/select-billing-address', 'Magento_Checkout/js/checkout-data', 'Magento_Checkout/js/model/checkout-data-resolver', 'Magento_Customer/js/customer-data', 'Magento_Checkout/js/action/set-billing-address', 'Magento_Ui/js/modal/modal', 'Magento_Ui/js/model/messageList', 'mage/translate', 'mage/url' ], function ( $, ko, _, mediaCheck, mageUtils, Component, customer, address, addressList, addressConverter, quote, formPopUpState, editBillingAddress, createBillingAddress, selectBillingAddress, checkoutData, checkoutDataResolver, customerData, setBillingAddressAction, modal, globalMessageList, $t, url ) { 'use strict'; var popUp = null; return Component.extend({ defaults: { template: 'Tigren_AdvancedCheckout/billing', billingFormTemplate: 'Tigren_AdvancedCheckout/billing-address/form' }, visible: ko.observable(!quote.isVirtual()), errorValidationMessage: ko.observable(false), isCustomerLoggedIn: customer.isLoggedIn, isFormPopUpVisible: formPopUpState.isVisible, isFormInline: addressList().length === 0, isNewAddressAdded: ko.observable(false), saveInAddressBook: 1, quoteIsVirtual: quote.isVirtual(), /** * @return {exports} */ /** * Init component */ initialize: function () { this._super(); quote.paymentMethod.subscribe(function () { checkoutDataResolver.resolveBillingAddress(); }, this); }, /** * @return {exports.initObservable} */ initObservable: function () { var self = this, hasNewAddress; this._super() .observe({ selectedAddress: null, isAddressFormVisible: true, isAddressSameAsShipping: false, isAddressFormListVisible: false, saveInAddressBook: 1 }); quote.billingAddress.subscribe(function (newAddress) { if (quote.isVirtual()) { this.isAddressSameAsShipping(false); } else { this.isAddressSameAsShipping( newAddress != null && quote.shippingAddress() && newAddress.getCacheKey() === quote.shippingAddress().getCacheKey() //eslint-disable-line eqeqeq ); } if (newAddress != null && newAddress.saveInAddressBook !== undefined) { this.saveInAddressBook(newAddress.saveInAddressBook); } else { this.saveInAddressBook(1); } }, this); checkoutDataResolver.resolveBillingAddress(); hasNewAddress = addressList.some(function (address) { return address.getType() === 'new-customer-address' || address.getType() === 'new-billing-address'; //eslint-disable-line eqeqeq }); this.isNewAddressAdded(hasNewAddress); this.isFormPopUpVisible.subscribe(function (value) { if (value) { self.getPopUp().openModal(); } }); return this; }, /** * Navigator change hash handler. * * @param {Object} step - navigation step */ navigate: function (step) { step && step.isVisible(true); }, /** * @return {*} */ getPopUp: function () { var self = this, buttons; if (!popUp) { buttons = this.popUpForm.options.buttons; this.popUpForm.options.buttons = [ { text: buttons.save.text ? buttons.save.text : $t('Save Address'), class: buttons.save.class ? buttons.save.class : 'action primary action-save-address', click: self.saveNewAddress.bind(self) }, { text: buttons.cancel.text ? buttons.cancel.text : $t('Cancel'), class: buttons.cancel.class ? buttons.cancel.class : 'action secondary action-hide-popup', /** @inheritdoc */ click: this.onClosePopUp.bind(this) } ]; /** @inheritdoc */ this.popUpForm.options.closed = function () { self.isFormPopUpVisible(false); }; this.popUpForm.options.modalCloseBtnHandler = this.onClosePopUp.bind(this); this.popUpForm.options.keyEventHandlers = { escapeKey: this.onClosePopUp.bind(this) }; /** @inheritdoc */ this.popUpForm.options.opened = function () { // Store temporary address for revert action in case when user click cancel action self.temporaryAddress = $.extend(true, {}, checkoutData.getBillingAddressFromData()); }; popUp = modal(this.popUpForm.options, $(this.popUpForm.element)); } return popUp; }, /** * Revert address and close modal. */ onClosePopUp: function () { checkoutData.getBillingAddressFromData($.extend(true, {}, this.temporaryAddress)); this.getPopUp().closeModal(); }, /** * Show address form popup */ showFormPopUp: function () { this.isFormPopUpVisible(true); }, /** * Save new billing address */ saveNewAddress: function () { var addressData, newBillingAddress; this.source.set('params.invalid', false); this.triggerBillingDataValidateEvent(); if (!this.source.get('params.invalid')) { addressData = this.source.get('billingAddress'); // if user clicked the checkbox, its value is true or false. Need to convert. addressData['save_in_address_book'] = this.saveInAddressBook ? 1 : 0; // New address must be selected as a billing address newBillingAddress = createBillingAddress(addressData); selectBillingAddress(newBillingAddress); checkoutData.setSelectedBillingAddress(newBillingAddress.getKey()); checkoutData.setNewCustomerBillingAddress($.extend(true, {}, addressData)); this.getPopUp().closeModal(); this.isNewAddressAdded(true); } }, /** * Trigger Billing data Validate Event. */ triggerBillingDataValidateEvent: function () { this.source.trigger('billingAddress.data.validate'); if (this.source.get('billingAddress.custom_attributes')) { this.source.trigger('billingAddress.custom_attributes.data.validate'); } }, }); });
Step 9: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\js\view\shipping.js
/** * @author Tigren Team * @copyright Copyright (c) 2015 Tigren (https://www.tigren.com) * @package Tigren_AdvancedCheckout */ define([ 'jquery', 'underscore', 'ko', 'Magento_Customer/js/model/customer', 'Magento_Customer/js/model/address-list', 'Magento_Checkout/js/model/address-converter', 'Magento_Checkout/js/model/quote', 'Magento_Checkout/js/action/create-shipping-address', 'Magento_Checkout/js/action/select-shipping-address', 'Magento_Checkout/js/action/create-billing-address', 'Magento_Checkout/js/action/select-billing-address', 'Magento_Checkout/js/model/shipping-rates-validator', 'Magento_Checkout/js/model/shipping-address/form-popup-state', 'Magento_Checkout/js/model/shipping-service', 'Magento_Checkout/js/action/select-shipping-method', 'Magento_Checkout/js/model/shipping-rate-registry', 'Magento_Checkout/js/action/set-shipping-information', 'Magento_Checkout/js/model/step-navigator', 'Magento_Ui/js/modal/modal', 'Magento_Checkout/js/model/checkout-data-resolver', 'Magento_Checkout/js/checkout-data', 'uiRegistry', 'mage/translate', 'Magento_Checkout/js/model/shipping-rate-service' ], function ( $, _, ko, customer, addressList, addressConverter, quote, createShippingAddress, selectShippingAddress, createBillingAddress, selectBillingAddress, shippingRatesValidator, formPopUpState, shippingService, selectShippingMethodAction, rateRegistry, setShippingInformationAction, stepNavigator, modal, checkoutDataResolver, checkoutData, registry, $t ) { 'use strict'; var popUp = null; return function (Component) { return Component.extend({ defaults: { template: 'Tigren_AdvancedCheckout/shipping', }, isAddressSameAsShipping: ko.observable(true), isShowBillingForm: ko.observable(false), initChildren: function () { this.messageContainer = new Messages(); this.createMessagesComponent(); return this; }, createMessagesComponent: function () { var messagesComponent = { parent: this.name, name: this.name + '.messages', displayArea: 'messages', component: 'Magento_Ui/js/view/messages', config: { messageContainer: this.messageContainer } }; layout([messagesComponent]); return this; }, setShippingInformation: function () { if (this.validateShippingInformation() && this.validateBillingInformation()) { setShippingInformationAction().done(function () { stepNavigator.next(); }); } }, /** * @return {Boolean} */ validateShippingInformation: function () { var shippingAddress, addressData, loginFormSelector = 'form[data-role=email-with-possible-login]', emailValidationResult = customer.isLoggedIn(), field; if (!quote.shippingMethod()) { this.errorValidationMessage($t('Please specify a shipping method.')); return false; } if (!customer.isLoggedIn()) { $(loginFormSelector).validation(); emailValidationResult = Boolean($(loginFormSelector + ' input[name=username]').valid()); } if (this.isFormInline) { this.source.set('params.invalid', false); this.triggerShippingDataValidateEvent(); if (emailValidationResult && this.source.get('params.invalid') || !quote.shippingMethod()['method_code'] || !quote.shippingMethod()['carrier_code'] ) { this.focusInvalid(); return false; } shippingAddress = quote.shippingAddress(); addressData = addressConverter.formAddressDataToQuoteAddress( this.source.get('shippingAddress') ); //Copy form data to quote shipping address object for (field in addressData) { if (addressData.hasOwnProperty(field) && //eslint-disable-line max-depth shippingAddress.hasOwnProperty(field) && typeof addressData[field] != 'function' && _.isEqual(shippingAddress[field], addressData[field]) ) { shippingAddress[field] = addressData[field]; } else if (typeof addressData[field] != 'function' && !_.isEqual(shippingAddress[field], addressData[field])) { shippingAddress = addressData; break; } } if (customer.isLoggedIn()) { shippingAddress['save_in_address_book'] = 1; } selectShippingAddress(shippingAddress); } if (!emailValidationResult) { $(loginFormSelector + ' input[name=username]').focus(); return false; } return true; }, validateBillingInformation: function () { var addressData, newBillingAddress; if ($('[name="billing-address-same-as-shipping"]').is(":checked")) { if (this.isFormInline) { var shippingAddress = quote.shippingAddress(); addressData = addressConverter.formAddressDataToQuoteAddress( this.source.get('shippingAddress') ); //Copy form data to quote shipping address object for (var field in addressData) { if (addressData.hasOwnProperty(field) && shippingAddress.hasOwnProperty(field) && typeof addressData[field] !== 'function' && _.isEqual(shippingAddress[field], addressData[field]) ) { shippingAddress[field] = addressData[field]; } else if (typeof addressData[field] !== 'function' && !_.isEqual(shippingAddress[field], addressData[field])) { shippingAddress = addressData; break; } } if (customer.isLoggedIn()) { shippingAddress.save_in_address_book = 1; } newBillingAddress = createBillingAddress(shippingAddress); selectBillingAddress(newBillingAddress); } else { var billingAddress = quote.shippingAddress(); selectBillingAddress(billingAddress); } return true; } var selectedAddress = quote.billingAddress(); if (selectedAddress) { if (selectedAddress.customerAddressId) { return addressList.some(function (address) { if (selectedAddress.customerAddressId === address.customerAddressId) { selectBillingAddress(address); return true; } return false; }); } else if (selectedAddress.getType() === 'new-customer-address' || selectedAddress.getType() === 'new-billing-address') { return true; } } this.source.set('params.invalid', false); this.source.trigger('billingAddress.data.validate'); if (this.source.get('billingAddress.custom_attributes')) { this.source.trigger('billingAddress.custom_attributes.data.validate'); } if (this.source.get('params.invalid')) { return false; } addressData = this.source.get('billingAddress'); if ($('#billing-save-in-address-book').is(":checked")) { addressData.save_in_address_book = 1; } newBillingAddress = createBillingAddress(addressData); selectBillingAddress(newBillingAddress); return true; }, /** * @return {Boolean} */ useShippingAddress: function () { if (this.isAddressSameAsShipping()) { this.isShowBillingForm(false); } else { this.isShowBillingForm(true); } return true; }, }); } });
Step 10: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\js\view\billing-address\list.js
/** * @author Tigren Team * @copyright Copyright (c) 2015 Tigren (https://www.tigren.com) * @package Tigren_AdvancedCheckout */ define([ 'underscore', 'ko', 'mageUtils', 'uiComponent', 'uiLayout', 'Magento_Customer/js/model/address-list' ], function (_, ko, utils, Component, layout, addressList) { 'use strict'; var defaultRendererTemplate = { parent: '${ $.$data.parentName }', name: '${ $.$data.name }', component: 'Tigren_AdvancedCheckout/js/view/billing-address/address-renderer/default' }; return Component.extend({ defaults: { template: 'Tigren_AdvancedCheckout/billing-address/list', visible: addressList().length > 0, rendererTemplates: [] }, /** @inheritdoc */ initialize: function () { this._super() .initChildren(); addressList.subscribe(function (changes) { var self = this; changes.forEach(function (change) { if (change.status === 'added') { self.createRendererComponent(change.value, change.index); } }); }, this, 'arrayChange' ); return this; }, /** @inheritdoc */ initConfig: function () { this._super(); // the list of child components that are responsible for address rendering this.rendererComponents = []; return this; }, /** @inheritdoc */ initChildren: function () { _.each(addressList(), this.createRendererComponent, this); return this; }, /** * Create new component that will render given address in the address list * * @param {Object} address * @param {*} index */ createRendererComponent: function (address, index) { var rendererTemplate, templateData, rendererComponent; if (index in this.rendererComponents) { this.rendererComponents[index].address(address); } else { // rendererTemplates are provided via layout rendererTemplate = address.getType() != undefined && this.rendererTemplates[address.getType()] != undefined ? //eslint-disable-line utils.extend({}, defaultRendererTemplate, this.rendererTemplates[address.getType()]) : defaultRendererTemplate; templateData = { parentName: this.name, name: index }; rendererComponent = utils.template(rendererTemplate, templateData); utils.extend(rendererComponent, { address: ko.observable(address) }); layout([rendererComponent]); this.rendererComponents[index] = rendererComponent; } } }); });
Step 11: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\js\view\billing-address\address-renderer\default.js
/** * @author Tigren Team * @copyright Copyright (c) 2015 Tigren (https://www.tigren.com) * @package Tigren_AdvancedCheckout */ define([ 'jquery', 'ko', 'uiComponent', 'Magento_Checkout/js/action/select-billing-address', 'Magento_Checkout/js/model/quote', 'Tigren_AdvancedCheckout/js/model/billing-address/form-popup-state', 'Magento_Checkout/js/checkout-data', 'Magento_Customer/js/customer-data' ], function ($, ko, Component, selectBillingAddressAction, quote, formPopUpState, checkoutData, customerData) { 'use strict'; var countryData = customerData.get('directory-data'); return Component.extend({ defaults: { template: 'Tigren_AdvancedCheckout/billing-address/address-renderer/default' }, /** @inheritdoc */ initObservable: function () { this._super(); this.isSelected = ko.computed(function () { var isSelected = false, billingAddress = quote.billingAddress(); if (billingAddress) { isSelected = billingAddress.getKey() == this.address().getKey(); //eslint-disable-line eqeqeq } return isSelected; }, this); return this; }, /** * @param {String} countryId * @return {String} */ getCountryName: function (countryId) { return countryData()[countryId] != undefined ? countryData()[countryId].name : ''; //eslint-disable-line }, /** Set selected customer shipping address */ selectAddress: function () { selectBillingAddressAction(this.address()); checkoutData.setSelectedBillingAddress(this.address().getKey()); }, /** * Edit address. */ editAddress: function () { formPopUpState.isVisible(true); this.showPopup(); }, /** * Show popup. */ showPopup: function () { $('[data-open-modal="opc-new-billing-address"]').trigger('click'); } }); });
Step 12: Add the file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\billing-address\address-renderer\default.html
/**
* @author Tigren Team
* @copyright Copyright (c) 2015 Tigren (https://www.tigren.com)
* @package Tigren_AdvancedCheckout
*/
-->
<!-- ko if: (visible()) -->
<!-- ko text: address().prefix --><!-- /ko --> <!-- ko text: address().firstname --><!-- /ko --> <!-- ko text: address().middlename --><!-- /ko -->
<!-- ko text: address().lastname --><!-- /ko --> <!-- ko text: address().suffix --><!-- /ko --><br/>
<!-- ko text: _.values(address().street).join(", ") --><!-- /ko --><br/>
<!-- ko text: address().city --><!-- /ko -->, <span data-bind="html: address().region"></span> <!-- ko text: address().postcode --><!-- /ko --><br/>
<!-- ko text: getCountryName(address().countryId) --><!-- /ko --><br/>
<!-- ko if: (address().telephone) -->
<a data-bind="text: address().telephone, attr: {'href': 'tel:' + address().telephone}"></a>
<!-- /ko --><br/>
<!-- ko foreach: { data: address().customAttributes, as: 'element' } -->
<!-- ko foreach: { data: Object.keys(element), as: 'attribute' } -->
<!-- ko if: (typeof element[attribute] === "object") -->
<!-- ko text: element[attribute].value --><!-- /ko -->
<!-- /ko -->
<!-- ko if: (typeof element[attribute] === "string") -->
<!-- ko text: element[attribute] --><!-- /ko -->
<!-- /ko --><br/>
<!-- /ko -->
<!-- /ko -->
<!-- /ko -->
Step 13: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\address.html
<li id="shipping" class="checkout-shipping-address" data-bind="fadeVisible: visible()"> <div class="step-title" data-bind="i18n: 'Shipping Address'" data-role="title"></div> <div id="checkout-step-shipping" class="step-content" data-role="content"> <!-- ko if: (!quoteIsVirtual) --> <!-- ko foreach: getRegion('customer-email') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <!--/ko--> <!-- ko foreach: getRegion('address-list') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <!-- ko foreach: getRegion('address-list-additional-addresses') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <!-- Address form pop up --> <!-- ko if: (!isFormInline) --> <button type="button" data-bind="click: showFormPopUp, visible: !isNewAddressAdded()" class="action action-show-popup"> <span data-bind="i18n: 'New Address'"></span></button> <div id="opc-new-shipping-address" data-bind="visible: isFormPopUpVisible()"> <!-- ko template: 'Magento_Checkout/shipping-address/form' --><!-- /ko --> </div> <!-- /ko --> <!-- ko foreach: getRegion('before-form') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <!-- Inline address form --> <!-- ko if: (isFormInline) --> <!-- ko template: 'Magento_Checkout/shipping-address/form' --><!-- /ko --> <!-- /ko --> <!-- ko if: (isFormInline) --> <!-- /ko --> <!-- Inline Billing address form --> <!-- ko foreach: getRegion('billing-address') --> <!-- ko template: getTemplate() --><!-- /ko --> <!-- /ko --> </div> </li> <!--Shipping method template--> <li id="opc-shipping_method" class="checkout-shipping-method" data-bind="fadeVisible: visible(), blockLoader: isLoading" role="presentation"> <div class="checkout-shipping-method"> <div class="step-title" data-bind="i18n: 'Shipping Methods'" data-role="title"></div> <!-- ko foreach: getRegion('before-shipping-method-form') --> <!-- ko template: getTemplate() --><!-- /ko --> <!-- /ko --> <div id="checkout-step-shipping_method" class="step-content" data-role="content" role="tabpanel" aria-hidden="false"> <!-- ko if: rates().length --> <form class="form methods-shipping" id="co-shipping-method-form" data-bind="submit: setShippingInformation" novalidate="novalidate"> <div id="checkout-shipping-method-load"> <table class="table-checkout-shipping-method"> <thead> <tr class="row"> <th class="col col-method" data-bind="i18n: 'Select Method'"></th> <th class="col col-price" data-bind="i18n: 'Price'"></th> <th class="col col-method" data-bind="i18n: 'Method Title'"></th> <th class="col col-carrier" data-bind="i18n: 'Carrier Title'"></th> </tr> </thead> <tbody> <!--ko foreach: { data: rates(), as: 'method'}--> <tr class="row" data-bind="click: $parent.selectShippingMethod"> <td class="col col-method"> <!-- ko ifnot: method.error_message --> <!-- ko if: $parent.rates().length == 1 --> <input class="radio" type="radio" data-bind="attr: { checked: $parent.rates().length == 1, 'value' : method.carrier_code + '_' + method.method_code, 'id': 's_method_' + method.method_code, 'aria-labelledby': 'label_method_' + method.method_code + '_' + method.carrier_code + ' ' + 'label_carrier_' + method.method_code + '_' + method.carrier_code }" /> <!-- /ko --> <!--ko ifnot: ($parent.rates().length == 1)--> <input type="radio" data-bind=" value: method.carrier_code + '_' + method.method_code, checked: $parent.isSelected, attr: { 'id': 's_method_' + method.carrier_code + '_' + method.method_code, 'aria-labelledby': 'label_method_' + method.method_code + '_' + method.carrier_code + ' ' + 'label_carrier_' + method.method_code + '_' + method.carrier_code }, click: $parent.selectShippingMethod" class="radio"/> <!--/ko--> <!-- /ko --> </td> <td class="col col-price"> <!-- ko foreach: $parent.getRegion('price') --> <!-- ko template: getTemplate() --><!-- /ko --> <!-- /ko --> </td> <td class="col col-method" data-bind="text: method.method_title, attr: {'id': 'label_method_' + method.method_code + '_' + method.carrier_code}"></td> <td class="col col-carrier" data-bind="text: method.carrier_title, attr: {'id': 'label_carrier_' + method.method_code + '_' + method.carrier_code}"></td> </tr> <!-- ko if: method.error_message --> <tr class="row row-error"> <td class="col col-error" colspan="4"> <div class="message error"> <div data-bind="text: method.error_message"></div> </div> <span class="no-display"> <input type="radio" data-bind="attr: {'value' : method.method_code, 'id': 's_method_' + method.method_code}"/> </span> </td> </tr> <!-- /ko --> <!-- /ko --> </tbody> </table> </div> <div id="onepage-checkout-shipping-method-additional-load"> <!-- ko foreach: getRegion('shippingAdditional') --> <!-- ko template: getTemplate() --><!-- /ko --> <!-- /ko --> </div> <!-- ko if: errorValidationMessage().length > 0 --> <div class="message notice"> <span><!-- ko text: errorValidationMessage()--><!-- /ko --></span> </div> <!-- /ko --> <div class="actions-toolbar" id="shipping-method-buttons-container"> <div class="primary"> <button data-role="opc-continue" type="submit" class="button action continue primary"> <span><!-- ko i18n: 'Next'--><!-- /ko --></span> </button> </div> </div> </form> <!-- /ko --> <!-- ko ifnot: rates().length > 0 --><div class="no-quotes-block"><!-- ko i18n: 'Sorry, no quotes are available for this order at this time'--><!-- /ko --></div><!-- /ko --> </div> </div> </li>
Step 14: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\billing.html
<div class="checkout-billing-address"> <!-- ko foreach: getRegion('billing-address-list') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <!-- Inline address form --> <render if="isFormInline" args="billingFormTemplate"/> </div> <!-- Address form pop up --> <if args="!isFormInline"> <button type="button" class="action action-show-popup" click="showFormPopUp" visible="!isNewAddressAdded()"> <span translate="'New Address'"/> </button> <div id="opc-new-billing-address" visible="isFormPopUpVisible()" render="billingFormTemplate"/> </if>
Step 15: create file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\billing-address.html
<div class="checkout-billing-address"> <div class="billing-address-same-as-shipping-block field choice" data-bind="visible: canUseShippingAddress()"> <input type="checkbox" name="billing-address-same-as-shipping" data-bind="checked: isAddressSameAsShipping, click: useShippingAddress, attr: {id: 'billing-address-same-as-shipping'}"/> <label data-bind="attr: {for: 'billing-address-same-as-shipping'}"> <span data-bind="i18n: 'This address is also my billing address'"></span> </label> </div> <fieldset class="fieldset"> <!-- ko template: 'Tigren_AdvancedCheckout/billing-address/list' --><!-- /ko --> <!-- ko template: 'Tigren_AdvancedCheckout/billing-address/form' --><!-- /ko --> </fieldset> </div>
Step 16: create file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\shipping.html
<!-- /** * @author Tigren Team * @copyright Copyright (c) 2015 Tigren (https://www.tigren.com) * @package Tigren_AdvancedCheckout */ --> <li id="shipping" class="checkout-shipping-address" data-bind="fadeVisible: visible()"> <div class="step-title" translate="'Shipping Address'" data-role="title" /> <div id="checkout-step-shipping" class="step-content" data-role="content"> <each if="!quoteIsVirtual" args="getRegion('customer-email')" render="" /> <each args="getRegion('address-list')" render="" /> <each args="getRegion('address-list-additional-addresses')" render="" /> <!-- Address form pop up --> <if args="!isFormInline"> <button type="button" class="action action-show-popup" click="showFormPopUp" visible="!isNewAddressAdded()"> <span translate="'New Address'" /> </button> <div id="opc-new-shipping-address" visible="isFormPopUpVisible()" render="shippingFormTemplate" /> </if> <each args="getRegion('before-form')" render="" /> <!-- Inline address form --> <render if="isFormInline" args="shippingFormTemplate" /> <div class="step-title" translate="'Billing Address'" data-role="title" /> <div id="billing-address-container"> <div class="billing-address-same-as-shipping-block field choice"> <input type="checkbox" name="billing-address-same-as-shipping" data-bind="checked: isAddressSameAsShipping, click: useShippingAddress, attr: {id: 'billing-address-same-as-shipping-shared'}"/> <label data-bind="attr: {for: 'billing-address-same-as-shipping-shared'}"><span data-bind="i18n: 'Billing address is same as Delivery address (uncheck if you wish to use difference address).'"></span></label> </div> <div class="form-billing-address" data-bind="visible: isShowBillingForm"> <each args="getRegion('billing-address')" render=""/> </div> </div> </div> </li> <!--Shipping method template--> <li id="opc-shipping_method" class="checkout-shipping-method" data-bind="fadeVisible: visible(), blockLoader: isLoading" role="presentation"> <div class="checkout-shipping-method"> <div class="step-title" translate="'Shipping Methods'" data-role="title" /> <each args="getRegion('before-shipping-method-form')" render="" /> <div id="checkout-step-shipping_method" class="step-content" data-role="content" role="tabpanel" aria-hidden="false"> <form id="co-shipping-method-form" class="form methods-shipping" if="rates().length" submit="setShippingInformation" novalidate="novalidate"> <render args="shippingMethodListTemplate"/> <div id="onepage-checkout-shipping-method-additional-load"> <each args="getRegion('shippingAdditional')" render="" /> </div> <div role="alert" if="errorValidationMessage().length" class="message notice"> <span text="errorValidationMessage()" /> </div> <div class="actions-toolbar" id="shipping-method-buttons-container"> <div class="primary"> <button data-role="opc-continue" type="submit" class="button action continue primary"> <span translate="'Next'" /> </button> </div> </div> </form> <div class="no-quotes-block" ifnot="rates().length > 0" translate="'Sorry, no quotes are available for this order at this time'" /> </div> </div> </li>
Step 17: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\billing-address\list.html
<!-- ko foreach: getRegion('before-fields') -->
<!-- ko template: getTemplate() --><!-- /ko -->
<!--/ko-->
<form data-bind="attr: {'data-hasrequired': $t('* Required Fields')}">
<fieldset id="billing-new-address-form" class="fieldset address">
<!-- ko foreach: getRegion('additional-fieldsets') -->
<!-- ko template: getTemplate() --><!-- /ko -->
<!--/ko-->
<!-- ko if: (isCustomerLoggedIn) -->
<div class="field save-address">
<input type="checkbox" class="checkbox" id="billing-save-in-address-book"
data-bind="checked: saveInAddressBook"/>
<label class="label" for="billing-save-in-address-book">
<span data-bind="i18n: 'Save in address book'"></span>
</label>
</div>
<!-- /ko -->
</fieldset>
</form>
</div>
Step 18: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\billing-address\form.html
<div class="billing-address-form" data-bind="fadeVisible: isAddressFormVisible"> <!-- ko foreach: getRegion('before-fields') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <fieldset id="billing-new-address-form" class="fieldset address"> <!-- ko foreach: getRegion('additional-fieldsets') --> <!-- ko template: getTemplate() --><!-- /ko --> <!--/ko--> <!-- ko if: (isCustomerLoggedIn) --> <div class="field save-address"> <input type="checkbox" class="checkbox" id="billing-save-in-address-book" data-bind="checked: saveInAddressBook" /> <label class="label" for="billing-save-in-address-book"> <span data-bind="i18n: 'Save in address book'"></span> </label> </div> <!-- /ko --> </fieldset> </div> </div>
Step 19: create file app\code\Tigren\AdvancedCheckout\view\frontend\web\template\billing-address\custom-list.html
<!-- ko if: (visible)--> <div class="field addresses"> <div class="control"> <div class="billing-address-items"> <!-- ko foreach: { data: elems, as: 'element' } --> <!-- ko template: element.getTemplate() --><!-- /ko --> <!-- /ko --> </div> </div> </div> <!-- /ko -->
Step 20: Create the file app\code\Tigren\AdvancedCheckout\view\frontend\requirejs-config.js
var config = { config: { mixins: { 'Magento_Checkout/js/view/shipping': { 'Tigren_AdvancedCheckout/js/view/shipping': true }, } } };
Step 21: Run the following commands to initiate the module:
php bin\magento setup:upgrade php bin\magento setup:static-content:deploy -f php bin\magento cache:flush
Final Words
A clear Magento 2 Checkout Shipping Address Form can greatly enhance the user experience and streamline the checkout process. By moving the billing address under the shipping address, you can simplify the checkout flow, reducing friction for customers. This modification ensures a smoother and more efficient checkout experience, leading to increased customer satisfaction and higher conversion rates. Take advantage of these customization options to optimize your Magento 2 checkout and improve your online store’s performance.
